Adult Leg Phantom with Muscles for for X-Ray CT and Ultrasound
The Adult Leg (Muscles) Phantom is a realistic tool for studying and testing medical imaging devices. Based on the
average anatomy of a male leg, it includes bony and soft tissue features. The LG-A02 is suitable for various
X-Ray/CT and Ultrasound procedures and can be customized with pathologies or for specific training needs upon
request.
Adult Leg (Muscles) Phantom for X-Ray CT and Ultrasound is a realistic phantom designed based on the average anatomy
of a human male leg. It has all the essential bony and soft tissue features that make it an ideal tool to study,
research, and test medical imaging devices.
The LG-A02 can be used to study several diagnostic X-Ray CT and Ultrasound procedures in different orientation and
positioning techniques. Upon request, this product can be customized with different pathologies as well as for
specific training applications.
- Fibula Bone
- Tibia Bone
- Foot Bones
- Major Muscle Tissues
- Realistic Soft Body Tissue
- Adult Leg (Muscles) Phantom
- User Manual/Assembly Instructions
- 2-Year Warranty & Unlimited Customer Service
- Height: 38 x 10 x 7 in (approx.)
- Weight: 26.5 lbs (approx.)
- Height: 36 x 24 x 12 in (approx.)
- Weight: 35 lbs (approx.)
- Soft tissue and organs: Composition of urethane-based soft resin
- Synthetic bones: Patented ceramic-reinforced epoxy-based composite material
GTSimulators by Global Technologies
True Phantom Solutions Authorized Dealer
Design of the Phantom
Front view
Lateral view
Perspective view
Top view
Ultrasound Scans
X-Ray Scans
*/ These CT scans were obtained from our product, Adult Leg for X-Ray CT, MRI SKU: LG-A01. These are served as an example to refer to the imaging quality of this phantom. If you have any questions related to these, please write us at [email protected] /*
| Type of Tissue | Sound Velocity [m/s] | Density [g/cm³] | Hardness [Shore 00] | T2 [ms] | Hounsfield Value | Attenuation Measured at 2.25 MHz [dB/cm] |
|---|---|---|---|---|---|---|
| Cortical Bone | 3000 ± 30 | 2.31 | N/A | N/A | 1300 | 6.4 ± 0.3 |
| Trabecular Bone | 2800 ± 50 | 2.03 | N/A | N/A | 1300 | 21 ± 2 |
| Soft Tissue | 1400 ± 10 | 1.02 | 60 | 50 ms | 25 | 1.7 ± 0.2 |
| Muscle Tissue | 1400 ± 10 | 1.01 | 35 | 60 | N/A | 1.3 ± 0.2 |
| Thermal Conductivity | Volumetric Specific Heat Capacity | Thermal Diffusivity | Thermal Resistivity | Specific Heat | Speed of Sound |
|---|---|---|---|---|---|
| 0.776 W/ m K | 1.040 MJ/ m^3 K | 0.746 mm^2/ s | 1.289 m K/ W | 0.978 J/ g Deg Celsius | 3070 m/s |
| S.No. | Tissue Type | HU Value (average) |
|---|---|---|
| 1 | Trabecular Bone | 800 |
| 2 | Cortical Bone | 1300 |
